CMA CGM Norma - IMO 9299812

Name

CMA CGM NORMA

Type

Cellular Containership

IMO-number

9299812

Call sign

FMHQ

Flag

France

Previous flags

2006-22.02.2007 French Southern & Antarctic Territories

Port of registry

Marseille

GT

107.711 t

Suez GT

111.142 t

DWT

Summer: 113.909 t

NT

50.109 t

Number of 20ft containers

9.415

Container capacity 14t

6.945

Reefer point

700 reefer

Length

349,07 m overall
328,94 m between perpendiculars

Breadth

42,80 m

Draught

Summer: 15,02 m

Freeboard

Summer: 5.249 mm

Depth

27,30 m

Speed

25,8 knots

Built

2006

Date of completion

11.08.2006

Builder

Hyundai Samho Heavy Industries Co. Ltd.
Mokpo
South Korea

Yard number

S256

Hull material

Steel

Hull type

Single hull

Watertight compartments

13

Continuous decks

2

Main engine

1x Man B&W 12K98MC - 2 stroke 12 cylinder 980 x 2.660 mm diesel engine - 68.640 kW / 93.261 hp at 94,0 rpm
Built: 2006
Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div., Ulsan - South Korea

Propelling system

1x Screw propeller solid at 94 rpm

Boilers

1x CHO Aalborg 40,14 m² - 10,0 bar
1x CHR Aalborg 736,00 m² - 10,0 bar

Electrical installation

Power voltage: 6600 V
Lighting voltage: 220 V
Frequency: 60 Hz

Generators

3x Main diesel generatorsets each 2.933 kVA - 2.346 kW - 3.139 hp
2x Main diesel generatorsets each 3.733 kVA - 2.986 kW - 4.004 hp

Emergency generators

1x Diesel generatorset 625 kVA - 500 kW - 826 hp

Bow thruster

2.500 kW

Number of holds

10

Fuel capacity

14.602,4 m³

Crew

26

Cargo handling

3x Cranes - SWL 12,5 t each

Cargo gear

Gearless

Managing Owners

CMA CGM
Marseille

France

Operator

CMA CGM

Owner

Gie Opera 4 Bail
Marseille
France
