Westerschelde 11 November 2015 |
 |
| Westerschelde 09/11/15 |
|
Name |
COSCO FAITH |
|
Type |
Cellular containership - Carriage of dangerous goods - Refrigerated cargo |
|
IMO-number |
9472141 |
|
Call sign |
VRJL6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
141.823 t Suez: 146.208,17 t |
|
DWT |
Summer: 140.599 t |
|
NT |
63.544 t Suez: 134.399,15 t Panama: 144.985 t |
|
Displacement |
184.599 t |
|
Light ship |
44.179 t |
|
Number of 20ft containers |
13.092 |
|
Container capacity 14t |
9.000 |
|
Reefer capacity |
1.000 |
|
Length |
366,45 m overall 350,00 m between perpendiculars |
|
Breadth |
48,20 m moulded |
|
Draught |
Summer: 15,50 m |
|
Depth |
29,85 m moulded |
|
Freeboard |
4.959 mm |
|
Speed |
24,7 knots |
|
Built |
2012 |
|
Keel laid |
25/04/2011 |
|
Delivery date |
14/03/2012 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Management Dept., 1000 Bangeojinsunhwan-Doro, Dong-Gu, Ulsan South Korea |
|
Yard number |
2180 |
|
Hull material |
Steel |
|
Main engine |
1x Hyundai/MAN-B&W 12K98ME-C7 - 12 cylinder 980 x 2?400 mm combustion engine Mcr 72.240 kW / 98.2019 hp at 104,0 rpm Manufacturer: Hyundai Heavy Industries Co. Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler - 8,0 MPa 1x Exhaust gas economizer - 11,0 MPa Manufacturer: Kangrim Heavy Industries Co., Ltd. - South Korea |
|
Generators |
4x Main diesel generatorsets each 3.300 kW |
|
Number of holds |
10 |
|
Tank capacity |
Fuel oil: 13.146,10 m³ Lub oil: 747,60 m³ Fresh water: 605,80 m³ Ballast: 36.012,80 m³ Diesel oil: 1.038,70 m³ |
|
Lifting equipment |
1x Engine room overhead crane (After) - SWL 12,5 t 1x Engine room overhead crane (Forward) - SWL 12,5 t 1x Mono-rail hoist crane - SWL 12,5 t 1x Provision Crane (Port) - SWL 4,0 t 1x Provision Crane (Starboard) - SWL 4,0 t |
|
Cargo gear |
Gearless |
|
Commercial manager |
COSCO Shipping Lines Co Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
ISM manager |
Seaspan Shipmanagement (Seaspan Container Line) Suite 2600, 200, Granville Street Vancouver BC V6C 1S4 Canada |
|
Operator |
COSCO - China Ocean Shipping Company |
|
Registered owner |
Seaspan 2180 Ltd. Care of COSCO Shipping Lines Co Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
Latest data adjustment |
15 April 2024 |
