Westerschelde 25 January 2014 |
 |
 |
 |
||
| Westerschelde 25/01/14 | Westerschelde 08/06/15 | Westerschelde 24/10/17 |
|
Name |
RIO DE LA PLATA |
|
Type |
Cellular containership |
|
IMO-number |
9357951 |
|
Call sign |
9V8585 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flag |
05/2014 - 03/2018 Republic of Liberia, Monrovia - Call sign: D5CT8 |
|
GT |
73.899 t registered |
|
DWT |
80.454 t |
|
NT |
39.673 t registered |
|
Number of 20ft containers |
5.560 |
|
Number of 40ft containers |
1.085 |
|
Container capacity 14t |
4.100 |
|
Reefer capacity |
1.365 |
|
Length |
286,53 m overall 275,28 m registered |
|
Breadth |
40,00 m registered |
|
Draught |
13,50 m |
|
Freeboard |
5.974 mm |
|
Depth |
24,20 m moulded |
|
Speed |
24,7 knots |
|
Built |
2008 |
|
Keel laid |
12/11/2007 |
|
Launch date |
26/01/2008 |
|
Date of completion |
02/04/2008 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Okpo Shipyard |
|
Yard number |
4122 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä-HHI 8RTA96C-B - 2 stroke 8 cylinder 960 x 2.500 mm combustion engine - 57.760 kW at 102,0 rpm Year of manufacture: 2007 Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Solid propeller - aft at 102,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 78,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 393,0 m² Year of manufacture: 2007 Manufacturer: Alfa Laval Aalborg A/S |
|
Electric installations |
1x Plant 6.600 V - 3.857 kVA 3x Plants each 6.600 V - 5.857 kVA 1x Plant 450 V - 375 kVA 1x Plant 24 V - 20 Ah 1x Plant 24 V - 120 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah 2x Plants each 110 V - 55 Ah |
|
Generators |
3x MAN-B&W 9L32/40 main diesel generatorsets each 5.857,1 kVA / 4686 kW 1x MAN-B&W 6L32/40 main diesel generatorset 3.857,1 kVA / 3.086 kW |
|
Emergency generator |
1x Diesel generatorset 375 kVA |
|
Batteries |
1x Battery for automation 200 Ah 1x Battery for UPS radio 200 Ah 1x Battery for automation 120 Ah 2x Batteries for diesel control each 55 Ah 1x Battery for automation 20 Ah |
|
Compressed air receivers |
2x Receivers each 11.500 litres - 32,4 bar 2x Receivers each 600 litres - 32,4 bar 1x Receiver 2.000 litres - 8,6 bar 1x Receiver 200 litres - 7,9 bar |
|
Bow thruster |
1x Transverse thruster 2.000 kW, forward 1x Transverse thruster 1.500 kW, aft |
|
Number of holds |
9 |
|
Hold capacity |
151.703,9 m³ |
|
Number of tanks |
Ballast: 16 Fuel oil: 11 Lubricating oil: 9 Waste water: 3 Diesel oil: 3 Chain: 2 Sludge: 2 Fresh water: 2 |
|
Tank capacities 100% |
Diesel Oil: 357,6 m³ / 303,96 t Freshwater: 357,2 m³ Fuel Oil: 8.178,6 m³ / 8.015,02 t Lube Oil: 410,2 m³ / 369,95 t Tank Ballast: 20.769 m³ / 21.288,22 t |
|
Lifting equipment |
1x Engine room crane - SWL 11,5 t 1x Provisions crane - SWL 12,5 t |
|
Anchor equipment |
3x Anchors weight each 16.100 kg Chain length: 742,50 m Diameter: 97 mm |
|
Manager |
Hamburg-Südamerikanische Dampfschifffahrts-Gesellschaft KG |
|
Operator |
Columbus Shipmanagement GmbH Willy-Brandt-Str. 59-61 |
|
Registered owner |
A.P. Moller Singapore Pte. Ltd. |
|
Previous registered owner |
Containerschiffsreederei MS "RIO DE LA PLATA" GmbH & Co. KG - Federal Republic of Germany |
|
Latest data adjustment |
24 July 2018 |
