| Westerschelde 18 January 2020 |
|
Name |
CAP SAN VINCENT |
|
Type |
Cellular containership |
|
IMO-number |
9717228 |
|
Call sign |
V7XE5 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
Germany, Hamburg - Call sign: DJMG2 |
|
GT |
118.615 t Suez: 123.738,08 t |
|
DWT |
130.155,5 t |
|
NT |
53.419 t Suez: 110.207,76 t |
|
Number of 20ft containers |
10.600 |
|
Container capacity 14t |
8.500 |
|
Reefer capacity |
1.000 |
|
Length |
331,10 m overall 315,30 m between perpendiculars |
|
Breadth |
48,40 m moulded |
|
Draught |
Summer: 14,0 knots |
|
Freeboard |
4.987 mm |
|
Depth |
26,80 m moulded |
|
Speed |
Service: 21,0 knots Max: 23,0 knots |
|
Built |
2015 |
|
Keel laid |
24/03/2015 |
|
Delivery date |
25/09/2015 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co. Ltd. Geoje South Korea |
|
Yard number |
4289 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN 7S90ME-C10 - 2 stroke single acting 7 cylinder 900 x 3.260 mm combustion engine Mcr 40.670 kW / 55.295 hp at 84,0 rpm Manufacturer: Hyundai Heavy Industries Co. Ltd. |
|
Propellers |
1x Fixed pitch propeller - aft at 84,0 rpm Manufacturer: Hyundai Heavy Ind. Co., Ltd. |
|
Boilers |
1x Auxiliary boiler Aalborg CHB-5000 - 9,0 MPa 1x Unfired exhaust gas boiler Aalborg XS-2V - 9,0 MPa Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
2x Hyundai Himsen 9H32/40 - 4 stroke 9 cylinder 320 x 400 mm diesel engine each Mcr 4.500 kW connected with generatorset each 4.300 kW 2x Hyundai Himsen 6H32/40 - 4 stroke 9 cylinder 320 x 400 mm diesel engine each Mcr 3.000 kW connected with generatorset each 2.800 kW Manufacturer: Hyundai Heavy Ind. Co., Ltd. |
|
Bow thruster |
1x Tunnel thruster |
|
Cargo hold capacity |
237.041,30 m³ |
|
Tank capacities |
Ballast: 39.655,70 m³ Lub oil: 358,70 m³ Fuel oi: 9.001,70 m³ Diesel oil: 1.375,20 m³ Fresh water: 512,80 m³ |
|
Lifting equipment |
1x Provisions crane - SWL 12,5 t |
|
Cargo gear |
Gearless |
|
Crew size |
28 |
|
ISM & commercial manager |
Bernhard Schulte Bernhard Schulte House, 108, Middle Road Singapore City 188967 Republic of Singapore |
|
Operator |
Hamburg Süd - Hamburg Südamerikanische Dampfschifffahrts-Gesellschaft |
|
Registered owner |
SFL Vincent Inc. |
|
Latest data adjustment |
25 June 2023 |
