Westerschelde 24 September 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 01/11/18 | Westerschelde 25/07/19 | Zeebrugge 16/07/18 | Zeebrugge 16/07/18 | Zeebrugge 16/07/18 | Zeebrugge 16/07/18 | |||||
 |
 |
|||||||||
| Westerschelde 30/08/20 | Westerschelde 30/08/20 | |||||||||
|
Name |
HONOR |
|
Previous names |
1996 - 09/2005 Takasago |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier PCTC – Pure Car and truck Carrier |
|
IMO-number |
9126297 |
|
Call sign |
WDC6923 |
|
Flag |
United States of America |
|
Port of registry |
Wilmington, DE |
|
Previous flags |
1996 - 2005 Norway, Tønsberg - Call sign: LACR5 |
|
GT |
49.821 t registered |
|
DWT |
Summer: 19.860 t at maximum draft |
|
NT |
18.750 t registered |
|
Displacement |
35.103 t |
|
Length |
190,49 m overall 180,00 between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 10,20 m |
|
Air draft |
44,57 m |
|
Freeboard |
3.886 mm |
|
Depth |
31,40 m to upper deck |
|
Speed |
19,0 knots |
|
Built |
1996 |
|
Keel laid |
12/06/1996 |
|
Launch date |
15/09/1996 |
|
Date of completion |
17/12/1996 |
|
Builder |
Sumitomo Heavy Industries Marine & Engineering Co., Ltd. 19 Natsushima-cho 237-8555 Yokosuka Kanagawa Japan |
|
Yard number |
1214 |
|
Hull material |
Ordinary strength steel |
|
Hull type |
Single hull |
|
Watertight bulkheads |
3 |
|
Main engine |
1x Sulzer 6RTA62U - 6 cylinder combustion engine with an output of 12.975 kW at 109,0 rpm Manufacturer: Diesel United Ltd. |
|
Propellers |
1x Fixed 5 blades propeller and fitted with remote control from the bridge and control room |
|
Boilers |
1x Auxiliary exhaust gas boiler (Fire tube) - 7,0 bar 1x Auxiliary oil-fired boiler (Fire tube) - 7,0 bar Manufacturer: UNEX |
|
Generators |
3x MAN B&W Holfby 7L23/30 main diesel generatorsets with an output of 780 kW each |
|
Emergency generator |
1x MAN D-0226 MLE diesel generatorset |
|
Bow thruster |
1x Ulstein - 1.200 kW |
|
Hold volume |
121.065 m³ |
|
Capacity cars / trucks |
5.890 cars (RT43) or 803 trucks 1 RT43 unit = 7,38975 m² |
|
Number of decks |
12 + garage (of which 5 are hoist able) |
|
Number of tanks |
Ballast: 11 Fuel oil: 9 Sludge: 6 Lubricating oil: 5 Hydraulic oil: 3 Fresh water: 3 Chain: 2 Diesel oil: 2 Waste water: 2 |
|
Tank capacities 100% |
Diesel oil: 219,5 m³ Freshwater: 372,7 m³ Fuel oil: 2.544,2 m³ Hydraulic oil: 3,6 m³ Lube oil: 162,5 m³ Tank Ballast: 7.372,8 m³ |
|
Manager |
American Roll-On Roll-Off Maynard Drive Park Ridge NJ U.S.A. |
|
ISM Manager |
Tote Services, Inc 10550 Deerwood Park Blvd Suite 602 Jacksonville, FL, 32256 United States Of America |
|
Previous managers |
1996 - 2005 Wilhelmsen Ship Management (Norway) AS |
|
Operator |
ARC - American Roll On Roll Off Carrier Park Ridge NJ United States of America |
|
Registered owner |
Fidelio Limited Partnership Wilmington United States of America |
|
Previous names & owners |
1996 - 2005 Takasago - Wilhelmsen Lines Shipowning AS |
|
Renamed |
2022 Cape Arundel United States of America; Norfolk, VA - Call sign: WCAD owner: Marad - Div Of Reserve Fleet |
|
Latest data adjustment |
13 March 2023 |
