Name |
STORFJORD |
|
Type |
Roll-On/Roll-Off carrier - Ferry - Double ended ferry |
|
IMO-number |
9528469 |
|
Call sign |
LDKO |
|
Flag |
Norway |
|
Port of registry |
Molde |
|
GT |
2.967 t |
|
DWT |
Summer: 970 t |
|
NT |
891 t |
|
Displacement |
2.745 t |
|
Length |
109,93 m overall 108,00 m car deck 99,60 m between perpendiculars |
|
Breadth |
17,42 m |
|
Draught |
3,43 m |
|
Depth |
5,35 m |
|
Speed |
Max.: 13,8 knots |
|
Route |
2012 Festøy - Solavågen |
|
Built |
2011 |
|
Keel laid |
15/09/2009 |
|
Launch date |
04/05/2010 |
|
Delivery date |
19/01/2011 |
|
Builder |
Gdanska Stocznia Remontowa IM.J.P.SA |
|
Yard number |
1894-I/1 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
2x Mitsubishi S16R-MPTK diesel engine each 1.200 kW at 1.600 rpm |
|
Propellers |
1x Azimuth thrusters 1.200 kW Schottel STP1010, forward 1x Azimuth thrusters 1.200 kW Schottel STP1010, aft Cardan shafts between main engines and thrusters |
|
Generators |
2x Scania DI12 main diesel generatorsets each 236 kW |
|
Ro Ro ramps |
1x Centre or only length 2,80 m, 15-ton axle load each 1x Centre or only length 2,80 m, 15-ton axle load each |
|
Number of passengers |
292 |
|
Number of cars |
116 4,30 x 1,85 m |
|
Deck equipment |
High pressure hydraulic, remote operated, windlass |
|
Life Saving Equipment |
Life jackets and life buoys Four MES (Marine Escape System) stations for 150 passengers each 1x MOB boat with davit |
|
Tank capacities |
Fuel oil: 81 m³ |
|
Anchor equipment |
Length: 247,50 m Diameter: 36 mm |
|
Manager |
Fjord 1 ASA Strandavegen 15 |
|
Registered owner |
Fjord 1 ASA Strandavegen 15 |
|
Previous operator |
01/2011 - 10/2012 Fjord 1 MRF A.S., Molde - Norway |
|
Latest data adjustment |
04 October 2019 |
