Westerschelde 10 April 2015 |
 |
 |
 |
 |
 |
||||
| Westerschelde 10/04/15 | Westerschelde 18/09/19 | Westerschelde 18/09/19 | Westerschelde 27/04/17 | Westerschelde 27/04/17 | ||||
|
Name |
GLOVIS SUPREME |
|
Korean name |
글로비스 슈프림 |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier - Pure Car Carrier |
|
IMO-number |
9674177 |
|
Call sign |
D8GM |
|
Flag |
South Korea |
|
Port of registry |
JEJU |
|
Previous flag |
2013 - 2021 Marshall Islands, Majuro - Call sign: V7CR3 |
|
GT |
64.650 t |
|
DWT |
Summer: 20.138 t |
|
NT |
22.552 t |
|
Length |
199,97 m overall |
|
Breadth |
35,40 m |
|
Draught |
10,02 m |
|
Reg. dimensions L x B x D |
194,32 x 35,40 x 20,52 m |
|
Rule dimensions L x B x D |
188,80 x 35,40 x 14,48 m |
|
Freeboard |
Summer: 3.220 mm |
|
Depth |
14.48 m |
|
Speed |
Max.: 20,0 knots |
|
Built |
2013 |
|
Keel laid |
27/05/2013 |
|
Launch date |
31/08/2013 |
|
Date of completion |
08/11/2013 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Yeongam South Korea |
|
Yard number |
S-668 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x HHI/MAN-B&W 7S60ME-C8 - 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 13.070 kW / 17.770 bhp at 102,0 rpm Built: 03/05/2013 Builder: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Water tube boiler WTB - 8,8 kg/cm² Heating surface: 30,2 m² 1x Economizer EGE - 12,7 kg/cm² Heating surface: 483,0 m² Build: 02/04/2013 Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
1x Main diesel generatorset 1.250 kVA / 450 Volt 2x Main diesel generatorset 1.875 kVA / 450 Volt |
|
Number of cars |
7.280 |
|
Number of ramps |
2 |
|
Tank capacities |
Fuel oil: 3.452,2 m³ Fresh water: 320,7 m³ Water ballast: 9.233,2 m³ |
|
Commercial manager |
Hyundai Glovis Co., Ltd. 512, Yeongdong-daero, Gangnam-gu Seoul, 06172 South Korea |
|
ISM manager |
G-Marine Service Co., Ltd. 331, Jungang-daero, Dong-gu Busan, 48792 South Korea. |
|
Registered owner |
Hyundai Glovis Co., Ltd. 512, Yeongdong-daero, Gangnam-gu Seoul, 06172 South Korea |
|
Latest data adjustment |
06 August 2022 |
