Westerschelde 08 Septemner 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Vlissingen 08/04/15 | Vlissingen 08/04/15 | Westerschelde 12/08/15 | Westerschelde 12/08/15 | Westerschelde 12/08/15 | Westerschelde 12/08/15 | |||||
 |
|
| Antwerpen 09/04/15 | |
|
Name |
SILVERSTONE EXPRESS |
|
Type |
Roll-On/Roll-Off vehicle carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9434319 |
|
Call sign |
HO9130 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
2009 - 2016 Philippines, Manila - call sign: DUAR |
|
GT |
43.810 t registered |
|
DWT |
Summer: 15.154 t Winter: 14.339 t |
|
NT |
13.143 t registered |
|
Displacement |
Summer: 26.861 t Winter: 26.046 t |
|
Length |
180,00 m overall |
|
Breadth |
30,00 m moulded |
|
Draught |
Summer: 9,22 m Winter: 9,03 m |
|
Moulded L x B x D |
171,70 x 30,00 x 13,10 m |
|
Registered L x B x D |
174,34 x 30,00 x 20,13 m |
|
Keel to mast end |
44,53 m |
|
Freeboard |
Summer: 3.913 mm Winter: 4.105 mm |
|
Depth |
13,10 m moulded |
|
Speed |
Max.: 22,0 knots 19,9 knots full speed 16,80 knots eco speed |
|
Built |
2009 |
|
Keel laid |
18/10/2008 |
|
Launch date |
15/01/2009 |
|
Date of completion |
25/05/2009 |
|
Builder |
Mitsubishi Heavy Industries Ltd. Shimonoseki Shipyard & Machinery Works Shimonoseki Japan |
|
Yard number |
1132 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Main engine |
1x Mitsubishi 8UEC50LS II - 2 stroke single acting 8 cylinder 500 x 1.950 mm combustion engine 11.560 kW / 15.717 hp at 127,0 rpm Manufacturer: Mitsubishi Heavy Industries, Ltd. Kobe Shipyard & Machinery Works |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 560 mm |
|
Propellers |
1x Screw propeller solid |
|
Boilers |
1x Auxiliary Vertical boiler - 6,9 bar Evaporation: 1,80 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 1125 kVA - 900 kW - 1304 hp |
|
Emergency generators |
1x Diesel generatorset 125 kVA - 100 kW - 186 hp |
|
Bow thruster |
1x 1.200 kW |
|
Number of decks |
10 |
|
Deck area |
Deck 1: 2.070 m² Deck 2: 2.550 m² Deck 3: 2.720 m² Deck 4: 3.840 m² Deck 5: 4.180 m² Deck 6: 3.860 m² Deck 7: 4.640 m² Deck 8: 4.770 m² Deck 9: 4,730 m² Deck 10: 2.070 m² Total: 35.430 m² |
|
Liftable decks |
2 |
|
Mobile deck lifter |
1 |
|
Number of car decks |
10 No. 4, 6 liftable |
|
Number of ramps |
2 Stern ramp: 30,00 x 7,00 m - SWL 100 t Side ramp: 17,00 x 4,50 m - SWL 15 t |
|
Number of cars |
3.930 (basis RT 43 standard cars / 4,125m x1,55 m) |
|
Tank capacities |
Fuel oil: 1.793,2 m³ Diesel oil: 645,8 m³ Fresh water: 471,5 m² Water ballast: 7.291,3 m³ |
|
Manager |
Fleet Management Limited |
|
Operator |
Vroon Haven Westzijde 21 4511 AR Breskens The Netherlands |
|
Owner |
PCTC Express I B.V. Haven Westzijde 21 4511 AR Bresken The Netherlands |
|
Previous owner |
Sinagtala Maritime Management Inc. |
|
Renamed |
2019 Siem Curie Liberia, Monrovia - Call sign: D5UL4 Owner: Siem Shipowning I Norway AS, Kristiansand S - Norway Manager: Siem Car Carriers AS |
|
Latest data adjustment |
06 September 2023 |
