Name |
SLOMAN PROVIDER |
|
Type |
Multi purpose Ro-Ro / Lo-Lo and heavy lift vessel - Equipped for carriage of containers |
|
IMO-number |
9160994 |
|
Call sign |
V2BK8 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
7.260 t |
|
DWT |
8.194 t |
|
NT |
3.906 t |
|
Number of 20ft containers |
783 |
|
Containers capacity 14 t |
427 |
|
Reefer capacity |
40 on deck |
|
Length |
122,11 m overall 115,40 m between perpendiculars 116,13 m registered |
|
Breadth |
18,70 m registered |
|
Draught |
7,169 m |
|
Forecastle |
13,40 m |
|
Freeboard |
2.991 mm |
|
Depth |
10,15 m moulded |
|
Speed |
13,5 knots |
|
Built |
2000 |
|
Keel laid |
29.06.1998 |
|
Launch date |
27.07.2000 |
|
Date of completion |
11.2000 |
|
Builder |
Pendik Tersanesi ve Agir Sanayi |
|
Yard number |
22 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
6 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN 12 V 32/40 - 4 stroke 12 cylinder 320 x 400 mm diesel engine - 5.760 kW at 750 rpm Year of manufacture: 1999 Manufacturer: MAN Diesel & Turbo SE |
|
Propeller |
1x Controllable pitch propeller - aft at 185 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 35,0 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 121,0 m² Year of manufacture: 1998 Manufacturer: PWT Prozesswärmeträgertechnik GmbH |
|
Electric installations |
2x Plant 440/220 V each 325 kVA 1x Plant 440 V - 680 kVA 1x Plant 440 V - 343 kVA |
|
Shaft generator |
1x 680 kVA |
|
Generators |
2x Main diesel generatorsets each 325 kVA |
|
Emergency generator |
1x Diesel generatorset 343 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 400 kW, forward |
|
Cargo capacity |
Grain: 14.300 m³ Bales: 13.450 m³ |
|
Number of holds |
2 |
|
Tank capacities |
Fuel oil: 596 m³ Ballast water: 3.146 m³ |
|
Anchor equipment |
3x Anchors weight each 3.780 kg Chain length: 522,50 m |
|
Lifting devices |
2x Cranes - SWL 40 t each combinable up to 60 t |
|
Manager |
Sloman Neptun Schiffahrts-Aktiengesellschaft |
|
Operator |
Sloman Neptun |
|
Owner |
Sloman Neptun Schiffahrts-Aktiengesellschaft |
|
Last Update |
25.04.2013 |
