Westerschelde 17 October 2019 |
 |
 |
 |
||
| Westerschelde 24/06/14 | Westerschelde 02/11/16 | Westerschelde 16/03/19 | ||
|
Name |
RESOLVE |
|
Previous name |
1994 - 1996 Nosac Tanabata 1996 - 2003 Tanabata |
|
Type |
Roll-On/Roll-Off vehicles Carrier - Carriage of dangerous goods PCTC - Pure Car And Truck Carrier |
|
IMO-number |
9080297 |
|
Call sign |
KSOQ |
|
Flag |
United States of America |
|
Port of registry |
Wilmington, DE |
|
Previous flag |
Norway United States of America, Wilmington, DE - Call sign: WCZ5535 |
|
GT |
49.443 t registered |
|
DWT |
13.548 t |
|
NT |
18.548 t registered |
|
Length |
189,80 m overall 180,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 10,20 m |
|
Air draft |
45,49 m |
|
Freeboard |
3.886 mm |
|
Depth |
31,40 moulded |
|
Speed |
18,0 knots |
|
Built |
1994 |
|
Keel laid |
24/02/1994 |
|
Launch date |
17/08/1994 |
|
Delivery date |
01/11/1994 |
|
Builder |
Sumitomo Heavy Industries, Ltd. Oppama Shipyard 19 Natsushima-cho Yokosuka Japan |
|
Yard number |
1198 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkhead |
Water tight: 4 |
|
Main engine |
1x Diesel United-Sulzer 6RTA 62U - 6 cylinder combustion engine with an output of 12.975 kW / 17.400 hp at 109,0 rpm |
|
Propeller |
1x Fixed 5 blades propeller and fitted with remote control from the bridge and control room |
|
Auxiliary boiler |
1x Auxiliary Exhaust Gas Boiler (Fire Tube) – 7,0 bar 1x Auxiliary Oil-Fired Boiler (Fire Tube) - 7,0 bar |
|
Bow thruster |
1x 1.200 kW |
|
Generator |
3x Daihatsu 6DL24 main diesel generatorsets each 780 kW |
|
Emergency generator |
1x MAN D0226 MLE diesel generatorset 90 kW |
|
Hold capacity |
121.065 m³ |
|
Capacity car units (RT43) |
5.741 or 776 trucks 1 RT43 unit=7,38975 m² |
|
Ramp capacity Qtr |
Width: 13,80 m Height: 4,60 m Capacity: 120,0 t |
|
Ramp capacity Stbd |
Width: 5,00 m Height: 4,60 m Capacity: 26,5 t |
|
Stern ramp |
Width: 7,00 m Capacity: 120 t |
|
Below deck total area |
49.450 m² |
|
Below deck strong area |
20.040 m² |
|
Number of decks |
13 (of which 5 are hoistable) |
|
Number of tanks |
Fuel oil: 9 Ballast: 9 Sludge: 6 Lubricating oil: 5 Hydraulic oil: 3 Fresh water: 3 Chain: 2 Diesel oil: 2 Waste water: 2 |
|
Tank capacities 100% |
Diesel Oil: 217,9 m³ Freshwater: 372,7 m³ Fuel Oil: 2.544,1 m³ Hydraulic Oil: 3,6 m³ Lube Oil: 162,5 m³ Tank Ballast: 7.372,4 m³ |
|
Basic complement |
22 |
|
Manager |
Crowley Technical Management, Inc. 9487 Regency Square Blvd. Jacksonville, FL 32225 USA |
|
Previous managers |
1994-2001 American V.Ships Marine Ltd. ,Mineola, NY, 1150 - United States 2001-2004 Pacific-Gulf Marine Inc., New Orleans, LA, 70174-6479 - United States 2004 - 2010 TOTE Services Inc., Jacksonville United States |
|
Operator |
ARC - America Roll-On Roll-Off Carrier LLC 816 A1A N.,Suite 101, Ponte Vedra Beach FL 32082 USA |
|
Registered owner |
Fidelio Limited Partnership Inc. 85 Chestnut Ridge Rd 07645 1827 Montvale NJ United States |
|
Previous owner |
1994 - 2005 Wilmington Trust Company Trustee |
|
Renamed |
07/2023 Tanabata Marshall islands, Majuro - Call sign: V7A5698 Registered owner: Wilhelmsen Lines Shipowning Malta Limited |
|
Latest data adjustment |
26 December 2023 |
