| Zeebrugge 05 June 2012 |
 |
 |
 |
||
| Zeebrugge 05/06/12 | Zeebrugge 05/06/12 | Zeebrugge 14/10/11 |
|
Name |
QUEEN SAPPHIRE |
|
Type |
Vehicles carrier |
|
IMO-number |
9460887 |
|
Call sign |
9V7564 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
60.213 t |
|
DWT |
18.638 t |
|
NT |
18.573 t |
|
Length |
199,90 m |
|
Breadth |
32,26 m |
|
Draught |
Summer: 9,725 m |
|
Moulded L x B x D |
192,00 x 32,26 x 14,70 m |
|
Registered L x B x D |
194,31 x 32,26 x 21,25 m |
|
Freeboard |
Summer: 5.013 mm |
|
Depth |
36,02 m moulded |
|
Speed |
21,0 knots |
|
Built |
2009 |
|
Keel laid |
22.10.2008 |
|
Launch date |
06.06.2009 |
|
Date of completion |
30.09.2009 |
|
Builder |
Mitsubishi Heavy Industries, Ltd. |
|
Yard number |
2251 |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi - 2 stroke single acting 7 cylinder 600 x 2.300 mm diesel engine - 14.315 kW at 105,0 rpm Manufacturer: Mitsubishi Heavy Industries, Ltd. Kobe Shipyard & Machinery Works |
|
Number of screws |
1 |
|
Propeller Shaft |
1x Oil lubrication shaft with monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 2,80 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4x Main diesel generatorsets each 4.250 kVA |
|
Car capacity |
6340 |
|
Max. ramp weight |
100 t |
|
Max. cargo weight |
5,10 m |
|
Tank capacities |
Fuel oil: 2.887 m³ Fresh water: 566 m³ Water ballast: 9.261 m³ |
|
Lifting equipment |
2x Cranes - SWL 4,0 t each |
|
Crew |
23 |
|
Manager |
Orient Marine |
|
Operator |
Wallenius Wilhelmsen Line |
|
Registered owner |
Melodia Maritime Pte Ltd. |
