Zeebrugge 12 May 2022 |
 |
 |
|
| Zeebrugge 16/04/14 | Zeebrugge 16/04/14 |
|
Name |
STENA FORECASTER |
|
Type |
Roll-On/Roll-Off carrier |
|
IMO-number |
9214678 |
|
Call sign |
OYWT2 |
|
Flag |
Denmark |
|
Port of registry |
København |
|
Previous flags |
2003 - 2003 Sweden 2003 - 2003 United Kingdom, London - Call sign: MELO3 2003 Sweden, Göteborg - Call sign: SCKZ |
|
GT |
24.688 t |
|
DWT |
Summer: 12.300 t |
|
NT |
7.407 t |
|
Number of 20ft containers |
858 |
|
Length |
195,30 m overall 179,20 m between perpendiculars |
|
Breadth |
26,80 m extreme |
|
Draught |
7,50 m |
|
Lane metres |
Upper deck: 1.280 m Main deck: 1.190 m Tank top: 530 m Total: 3.000 m |
|
Depth |
8,70 m to main deck |
|
Speed |
22,0 knots |
|
Built |
2003 |
|
Keel laid |
12/07/2000 |
|
Launch date |
26/12/2000 |
|
Date of completion |
28/04/2003 |
|
Builder |
Dalian Shipbuilding Industry Company Dalian China |
|
Yard number |
RO123-2 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 6 Longitudinal: 2 |
|
Continuous decks |
2 |
|
Main engine |
4x Wärtsilä 8ZAL40S - 8 cylinder 400 x 500 mm combustion engines each 6.000 kW Total: 24.000 kW / 32.628 hp Builder: Wärtsilä Italia S.p.A |
|
Propellers |
2x KaMeWa Controllable pitch propeller - aft at 130,0 rpm Diameter: 5. 000 mm Builder: Rolls-Royce AB |
|
Boilers |
2x Auxiliary boiler, exhaust gas heated - Aalborg EGE 1A 1x Auxiliary boiler, exhaust gas heated - Aalborg AV-6N 2x Auxiliary boiler, oil/gas fired - Aalborg Mission OS 3300 Builder: Aalborg Industries A/S |
|
Generators |
2x Wärtsilä NSD 9L20C diesel generatorsets Builder: Wärtsilä Finland Oy |
|
Emergency generator |
1x MAN D2842LE diesel generatorset Builder: MAN Nutzfahrzeuge AG |
|
Bow thrusters |
2x Rolls Royce/KaMeWa TT2000 each 1.100 kW |
|
Vehicle decks |
Free Height: Upper deck 5,00 m Main deck: 6,80 m Tanktop: 5,10 m |
|
Trailer capacity |
180 |
|
Tank capacities |
Ballast: 6.744 m³ |
|
Anchor equipment |
Length: 632,05 m Diameter: 68 mm |
|
Number of passengers |
12 |
|
Number of beds |
12 |
|
Manager |
Stena Marine Management ApS |
|
Previous managers |
2003 - 2014 Northern Marine Management Ltd 2014 Northern Marine Ferries Limited - United Kingdom |
|
Registered owner |
Stena Rederi A/S Tuborg Boulevard 12 2900 Hellerup Denmark |
|
Previous owners |
2003 - 2003 Stena North Sea Ltd. 2003 - 2003 Stena Dragon Ltd. 2003 - 2003 Stena RoRo AB |
|
Latest data adjustment |
19 May 2022 |
