| Zeebrugge 27 February 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Zeebrugge 03/08/15 | Zeebrugge 03/08/15 | Zeebrugge 03/08/15 | Zeebrugge 03/08/15 | Zeebrugge 24/07/16 | Zeebrugge 31/06/09 |
|
Name |
OBERON |
|
Type |
Vehicles vessel LCTC - Large Car and Truck Carrier |
|
IMO-number |
9377509 |
|
Call sign |
SKJF |
|
Flag |
Sweden |
|
Port of registry |
Stockholm |
|
GT |
71.673 t |
|
DWT |
24.600 t |
|
NT |
33.513 t |
|
Length |
231,60 m overall 219,30 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 11,30 m |
|
Air draft |
51,98 m |
|
Height to upperdeck |
34,70 m |
|
Speed |
20,0 knots |
|
Line |
North Atlantic |
|
Built |
2008 |
|
Builder |
DSME - Daewoo Shipbuilding & Marine Engineering South Korea |
|
Yard number |
4450 |
|
Hull type |
Single hull |
|
Main engine |
1x B&W 8S60ME-C7 cobustion engine maximum output of 24.560 bhp at 105 rpm |
|
Propeller |
1x Fixed propeller |
|
Shaft generator |
1x 1.100 kW |
|
Generators |
2x STX-MAN-B&W type 9SL21/31 main diesel engine each coupled with 2 main generators 1.700 kW - 450 V, 60 Hz |
|
Emergency generator |
1x Diesel generatorset 215 kW |
|
Bow thruster |
Thrust force 30,0 t |
|
Number of cars RT 43 units |
8.000 1 RT43 gross unit abt. 8,40 m² |
|
Combination cars & buses |
Cars: 3.484 Buses: 466 |
|
Stern ramp |
Width: 9,50 m Height: 6,50 m Capacity: 320 t |
|
Number of car decks |
13 (of which 5 are movable) |
|
Capacity deck area |
67.000 m² |
|
Complement |
33 |
|
Crew |
19 |
|
Manager |
Wallenius Marine AB Stockholm Sweden |
|
Operator |
Wallenius Wilhelmsen Logistics |
|
Owner |
Walltrade AB Stockholm, 104 62 Sweden |
|
Previous owner |
Wallenius Lines AB Stockholm |
|
Latest data adjustment |
14 March 2019 |
